Specifications:
0: Width, 294 mm | 1: Depth, 180 mm | 2: Height, 44 mm
0: Basic switching RJ-45 Ethernet ports quantity, 8 | 1: Basic switching RJ-45 Ethernet ports type, Gigabit Ethernet (10/100/1000) | 2: Fiber ports quantity, 2 | 3: Fiber optic connector, SFP
0: Quality of Service QoS support, Y | 1: Networking standards, IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z | 2: Auto-negotiation, Y | 3: Jumbo frames support, Y | 4: Jumbo frames, 9000 | 5: 10G support, N | 6: Copper ethernet cabling technology, 10BASE-T,100BASE-TX | 7: VLAN support, Y | 8: Port mirroring, Y | 9: Virtual LAN features, MAC address-based VLAN,Protocol-based VLAN,Tagged VLAN,Voice VLAN | 10: Link aggregation, Y | 11: Broadcast storm control, Y | 12: Rate limiting, Y
0: Queue scheduling algorithms, SP, Weighted Round Robin (WRR) | 1: DHCP features, DHCP snooping,DHCPv6 snooping | 2: Access Control List ACL, Y
0: MAC address table, 8000 entries | 1: Number of queues, 8 | 2: Packet buffer memory, 0.5 MB | 3: Switching capacity, 20 Gbit/s | 4: Forwarding rate, 14.9 Mpps
0: Web-based management, Y | 1: System event log, Y | 2: MIB support, RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1213, RFC2233, RFC1643, RFC1493 | 3: Cloud-managed, Y
0: Fiber ethernet cabling technology, 100BASE-FX,1000BASE-X
0: Flow control support, Y | 1: Number of VLANs, 4000
0: Power over Ethernet PoE, Y | 1: Power over Ethernet PoE ports quantity, 8 | 2: Total Power over Ethernet PoE budget, 150 W
0: Operating temperature T-T, 0 - 50 °C | 1: Storage temperature T-T, -40 - 70 °C | 2: Operating relative humidity H-H, 10 - 90% | 3: Storage relative humidity H-H, 5 - 90%
0: Product colour, Black | 1: Number of fans, 1 fan(s)
0: Auto MDIMDI-X, Y
0: Certification, CE, FCC, RoHS
0: Multicast support, Y
0: Security algorithms, EAP-LEAP,EAP-MD5,EAP-TLS,EAP-TTLS,HTTPS,SNMP,SNMPv2,SNMPv3,SSH,SSH-2,SSL/TLS
